60/40 Micron Diamond Abrasive Powder Used In Machinery Good Impact Resistance

Henan Baililai Superhard Material Co., Ltd.
Contact Now

60/40 Micron Diamond Abrasive Powder Used In Machinery Good Impact Resistance

Brand Name : Henan Baililai Superhard Materials Co., Ltd.

Model Number : General Diamond Micron Powder

Certification : Henan Baililai Superhard Materials Co., Ltd.

Place of Origin : Henan China

Packaging Details : 4-layer packaging bag upside down head packaging, label affixed to the outermost layer

Product name : General Diamond Micron Powder

Abrasive grain sizes : 0/0.5 – 50/60

Usage : Polishing

state : powder

packaging : Bag and then carton

Contact Now

General Diamond Micron Powder

Introduction:

Diamond powder refers to fine particle size of 60/40 micron Diamond particles, is the choice of high-quality single Crystal Diamond as a raw material, crushing, shaping, purification, grading and other processes processed. Diamond powder high hardness, wear resistance, can be widely used in cutting, grinding, polishing, etc., is the ideal raw material for grinding and polishing tungsten carbide, ceramics, precious stones, optical glass and other high hardness materials.Diamond powder is widely used in machinery, Aerospace, optical instruments, glass, ceramics, electronics, petroleum, Geology, military industrial sectors, with the continuous development of technology and products, the use of diamond powder and products are still widening.

Specification table :

Grade

Size

ACM CSDM-D CSDM-C CSDM-B CSDM-A
0-0.05 Y Y Y
0-0.1 Y Y Y
0-0.125 Y Y Y
0-0.2 Y Y Y Y
0-0.25 Y Y Y Y
0-0.5 Y Y Y Y Y
0-1 Y Y Y Y Y
0-2 Y Y Y Y Y
1-2 Y Y Y Y Y
1-3 Y Y Y Y Y
2-3 Y Y Y Y Y
2-4 Y Y Y Y Y
2-5 Y Y Y Y Y
3-5 Y Y Y Y Y
4-6 Y Y Y Y Y
4-8 Y Y Y Y Y
5-7 Y Y Y Y Y
5-10 Y Y Y Y Y
6-12 Y Y Y Y Y
7-10 Y Y Y Y Y
8-12 Y Y Y Y Y
8-16 Y Y Y Y Y
10-14 Y Y Y Y Y
10-20 Y Y Y Y Y
14-20 Y Y Y Y Y
12-22 Y Y Y Y Y
15-25 Y Y Y Y Y
20-28 Y Y Y Y Y
20-30 Y Y Y Y Y
22-36 Y Y Y Y Y
20-40 Y Y Y Y Y
28-40 Y Y Y Y Y
30-40 Y Y Y Y Y
40-50 Y Y Y Y Y
40-60 Y Y Y Y Y
50-60 Y Y Y Y Y

Comparison table:

Chinese standards International standards Japanese standards/number of entries(#)

Russia

GOST9206-80

Median D50 (μm)
w0.2 0-0.2 80000 0.1
w0.25 0-0.25 60000 0.11~0.20
w0.5 0-0.5 30000 0.5/0 0.20~0.30
w1 0-1 15000 1/0 0.6~0.8
w1.5- 0-2 13000 0.8~1.0
w1.5 1-2 12000 2/1 1.1~1.3
w2.5 1-3 10000 1.6~1.8
W3 2-3 7000 3/2 1.9~2.1
w3.5 2-4 6000 2.6~3.0
W5- 2-5 5000 5/3 3.1~3.4
w5 3-6 4000 3.5~4.2
W5+ 4-6 3500 4.4~5.0
w7 4-8 3000 7/5 5.0~6.0
W7+ 4-9 2500 6.1~6.5
w10- 5-10 2000 10/7 6.5~7.3
w10 6-12 1800 7.3~8.3
w10+ 8-12 1600 8.3~9.0
w14- 7-14 1500 9.1~10.5
w14 8-16 1300 14/10 10.0~12.0
w20- 10-20 1200 12.5~15.0
w20 12-22 1000 20/14 15.0~17.0
w20+ 15-25 800 18.0~20.0
w28 20-30 700 28/20 20~23
w28+ 22-36 600 23~26
w40- 20-40 500 26~29
w40 30-40 450 40/28 29~32
w40+ 35-45 400 32~36
w50 40-60 350 60/40 37~43
